Pressure interlocking mechanism
- Boot, sterilization start, the sterilization process of the micro position switch real-time monitoring of the location of the chain mechanism, once there is an abnormal automatic alarm stop, to ensure safety
- The closed status of the lock girder is monitored by real-time position sensors. After sterilization, the temperature in the chamber is below 95 ° C, and the opening temperature can be arbitrarily set.
- Double overtemperature protection
- Double limit protection
- Heating tube to prevent dry burning - with hardware and software 3 protection, according to the water temperature rise rate to protect the dry burning outside, the standard PT1000 water temperature sensor accurately control the surface temperature of the heating tube to prevent dry burning damage, while the standard liquid expansion overtemperature protection protector, resulting in direct dry burning break protection
- Automatic intelligent control system

1. External removable pressure gauge for easy verification
2. USB as standard
3. peculiarity
- Sterilization temperature can be set up to 138 degrees
- PT1000 sensor, more accurate temperature control, display accuracy of 0.1 degrees
- Configurable negative pressure range -0.1-0.5 pressure gauge, overcurrent, short circuit protection system.
- Standard hardware and software dual function to prevent dry burning, overtemperature protection system, overpressure protection safety valve.
- Open cover to stop heating function
- After the sterilization is completed, the exhaust valve can be set at the ten-stage exhaust speed.
--Freertos embedded operating system
- Standard USB flash drive real-time data recording function
- With F0 value test function
- Automatic fault monitoring, alarm and recording function (optional printer required), anti-burn safety protection.
- Automatic detection of cold air emissions to ensure pure steam sterilization
- Boiling point temperature can be set according to altitude
- The exhaust temperature can be adjusted within the boiling point temperature plus 0~25 degrees
- Dual temperature sensors that can detect air and water temperature for safer use.
- The tank body is reserved for verification holes to verify the connection
- Mechanical pressure interlocking device closed cover inspection system
- Overcurrent protection device
